移动竹管，能窥见整只猎豹吗？
原创2026/4/20大约 21 分钟
想象一下我们平时看视频的体验：当摄像机跟随着主角的步伐，或是掠过一段壮丽的风景时，我们常常会被那种流畅的移动镜头所吸引。然而，受限于屏幕和镜头的物理画幅，我们的视线只能被禁锢在那个不断移动的矩形框内，始终无法同时将整个宏大的场景尽收眼底。
这就像是古人常说的管中窥豹——随着时间的推移，我们确实看到了猎豹身上的每一块斑纹，但由于视野受限，我们很难在脑海中瞬间拼凑出这只猎豹完整而震撼的全貌。
那么，有没有一种技术，能够打破时空的限制，将这段视频里随时间流逝的移动画面，全部展开并压缩进同一个平面，变成一张能让人纵览全貌的全景图呢？
答案是肯定的，这项技术被称为全景拼接。它的核心在于：通过计算机视觉算法，将时间轴上流动的离散画面提取出来，寻找它们之间的空间关联，再经过精准的对齐与融合，最终生成一张静态全景大图。接下来博主将介绍自己用 OpenCV 库实现这项技术的具体流程和细节。
注
这一套流程稳定工作的前提是：
- 镜头运动相对连贯平滑，没有极其剧烈的突发抖动。
- 主要拍摄对象大致处于同一平面上（比如扫拍一排建筑、一整面涂鸦墙或远处的山脉）。如果画面里远近物体交错太深（视差太大），拼接时就很容易出现割裂和重影。
生命周期总览
整个流程可以按生命周期拆成 4 个阶段：
- 参数解析与时间精确化：把输入的时间精准吸附到真实的视频帧上。
- 抽帧与关键帧筛选：剔除重复和模糊的废片，只留下最精华的关键帧。
- 帧间配准：通过特征匹配和单应性矩阵，让两张图找到彼此的位置。
- 建画布与多帧融合：建立全局大画布，把画面平滑地揉捏在一起，最后裁掉多余的黑边。
此外，代码还进一步做了性能增强：引入多线程和块处理，加快代码处理速度。
时间精确化
我们平时习惯用 HH:MM:SS.xxx（如 00:47:24.216）这样的连续时间来给视频定位，但视频的本质是离散的——它不过是一秒钟内闪过的几十张静态照片（帧）而已。
如果强行拿着带小数点的浮点时间去截取，而不把它“吸附”到最近的物理帧边界上，就会遇到一个极具迷惑性的 Bug：在不同的播放器里，明明输入的是同一个时间点，取出来的画面却总是差那么一两帧。
为了彻底消除这种偏差，我们的第一步必须严谨精确：先利用 ffprobe 强行嗅探出视频底层最真实的平均帧率（FPS），然后再把输入的秒数换算成绝对的物理帧索引。
def probe_video_fps(video_path: str) -> float:
cmd = [
"ffprobe", "-v", "error", "-select_streams", "v:0",
"-show_entries", "stream=avg_frame_rate",
"-of", "default=noprint_wrappers=1:nokey=1", video_path,
]
out = subprocess.check_output(cmd, text=True).strip()
if "/" in out:
return float(Fraction(out))
return float(out)
def snap_to_frame_time(time_sec: float, fps: float) -> tuple[int, float]:
idx = int(round(time_sec * fps))
return idx, idx / fps抽帧与关键帧筛选
有人可能会想：既然要拼全景，干脆把每一帧都拿来拼不就好了？但是不然，直接用所有帧会带来两个问题：
- 信息高度重复，计算量爆炸；
- 模糊帧和低质量帧会污染配准与融合结果。
相关信息
所谓模糊帧和低质量帧，通常是指摄像机在快速移动或手抖时产生的运动拖影，以及镜头未能及时跟上导致的虚焦画面。
这类画面缺乏锐利的边缘和纹理细节。如果强行参与计算，不仅会导致特征提取算法找不到足够的可靠特征点，进而引起两张图“对不齐”（配准误差）；在最终叠加混合时，还会像蒙上一层脏滤镜一样，将原本的模糊感和重影强加给最终的全景图，严重拉低整体画质。
因此，我们需要在这一步做两层筛选：先按 sample-fps 做候选抽样，再按清晰度（Laplacian 方差）和运动量（phase correlation 位移）筛出关键帧，只留下既清晰又带来了新视野的画面。
def blur_score(gray: np.ndarray) -> float:
return float(cv2.Laplacian(gray, cv2.CV_64F).var())
def estimate_motion(prev_gray: np.ndarray, curr_gray: np.ndarray) -> tuple[float, float]:
shift, response = cv2.phaseCorrelate(prev_gray.astype(np.float32), curr_gray.astype(np.float32))
dx, dy = shift
return math.hypot(dx, dy), float(response)if blur_score(gray) < blur_thr:
continue
motion_px, response = estimate_motion(last_kept_preview, gray)
elapsed = item.timestamp - last_kept_ts
if motion_px >= motion_thr or (elapsed >= keep_gap_sec and response < 0.20):
kept.append(item)对于那些本身就很短，或者镜头几乎没怎么动的片段，这套高标准可能会导致选不出关键帧。因此，我们加入了动态兜底机制：一旦发现剩余的帧数不够拼图了，程序会自动向下放宽清晰度和位移的阈值，避免有效关键帧不足而直接失败。
if len(keyframes) < 2:
keyframes = filter_candidates(...) # 调整参数以放宽阈值
if len(keyframes) < 2:
keyframes = candidates # 直接使用抽样出的所有帧帧间配准
拿到筛选好的关键帧后，接下来的核心任务是找到帧与帧之间的空间位置关系。具体来说，就是通过特征匹配找到两者的联系，并据此计算出决定它们位置关系的单应性矩阵。
相关信息
单应性矩阵（Homography Matrix）本质上是一个 3×3 的变形公式。在二维平面上，它可以将一张图片完美地拉伸、倾斜、扭曲成另一张图片的视角。在全景拼接中，我们利用它来消除相机的移动和旋转带来的视角差异，把连续的视频帧“压平”并对齐到同一个大画布上。
首先，我们利用 SIFT 或 ORB 算法提取出相邻图像各自的关键特征点；然后，通过比值测试剔除掉那些模棱两可的错误匹配；接着，将这些高质量的匹配点送入 cv2.findHomography，并结合 RANSAC 算法排除异常干扰，从而算出我们需要的变换矩阵 。为了保证最终的拼接质量，如果算出的内点率太低，我们会果断舍弃这次匹配。
相关信息
比值测试（Ratio Test）是一种专治算法“脸盲”的过滤机制。在匹配特征时，算法会为每个特征点寻找第一相似和第二相似的匹配点。只有当第一名的匹配度远远甩开第二名时（距离差距足够明显），才认为这是一个独一无二的有效匹配。这能完美过滤掉由于砖墙、波浪、树叶等大面积重复纹理带来的混淆错配。
内点率（Inlier Ratio）：RANSAC 算法在计算矩阵时，会将真正符合该矩阵变换规律的匹配点称为“内点”。内点占所有参与计算的匹配点的比例就是内点率。内点率越高，说明算出的变形公式越令人信服；如果太低（比如代码中低于 22%），说明匹配点里绝大多数都是瞎猜的噪点，算出的矩阵自然宁可不用。
src = np.float32([curr_pts[m.trainIdx] for m in good]).reshape(-1, 1, 2)
dst = np.float32([prev_pts[m.queryIdx] for m in good]).reshape(-1, 1, 2)
h, inliers = cv2.findHomography(src, dst, cv2.RANSAC, 3.0)
inlier_ratio = float(inliers.sum()) / max(1, len(inliers))
if inlier_ratio < 0.22:
return None算出了相邻两帧之间的变换矩阵后，为了把所有的图片都映射到同一块大画布上，我们需要通过矩阵的链式相乘，把它们串联推导到同一个坐标系下。
h_curr_to_0 = chain[-1] @ h_curr_to_prev
chain.append(h_curr_to_0)需要注意的是，如果单纯以第 0 帧作为全局的参考中心，随着矩阵越乘越多，微小的误差会像滚雪球一样累积，导致画面末尾出现非常夸张的拉伸变形。
为了避免这个问题，我们选取整个序列中最中间的那一帧作为真正的基准原点。通过计算它前方各帧的逆矩阵，将整条变换链重新映射过去。这样一来，长链条累积的畸变被均匀地向画面两端化解，整体比例会协调不少。
ref_idx = len(accepted) // 2
ref_inv = np.linalg.inv(chain[ref_idx])
transforms = [ref_inv @ h for h in chain]建画布与多帧融合
我们规划一张足够大的“无限画布”，随后将所有图片的四个角点，通过前面算好的变换矩阵投射到全局坐标系中，找出整个场景的极大和极小值，从而圈定全景图的绝对边界。
corners_all.append(cv2.perspectiveTransform(corners, h))
all_pts = np.concatenate(corners_all, axis=0).reshape(-1, 2)
min_x, min_y = np.min(all_pts, axis=0)
max_x, max_y = np.max(all_pts, axis=0)画布铺好了，最后一步就是把图片画上去。这里不能简单“贴图”，如果直接把新画面盖在旧画面上，天空和背景里会出现极其生硬的刀割般接缝；但如果无脑地将重叠区域的像素取平均值，画面又很容易糊成一团，产生强烈的雾化或重影。
为了在自然度和清晰度之间找到完美的平衡，我们在这里采用折中的办法：加权平均 + 边缘羽化 + 重叠区色彩微调。
实现边缘羽化的方法具体是：通过形态学的腐蚀操作和距离变换，为每一张图生成一个专属的“权重遮罩”。这个遮罩的中心区域是实心的（权重最高），越靠近边缘则越透明（权重递减）。有了它，图片边缘的像素就能以一种极其柔和的方式消散并融入底图中。
def build_soft_weight(shape: tuple[int, int], feather_radius: int) -> np.ndarray:
src_mask = np.full((h, w), 255, dtype=np.uint8)
inner = cv2.erode(src_mask, kernel)
dist = cv2.distanceTransform(inner, cv2.DIST_L2, 3)
dist = dist / float(dist.max())
return np.clip(dist, 0.05, 1.0).astype(np.float32)接着是真正的像素叠加。利用 NumPy 的矩阵运算，把经过形变处理的像素块乘以刚刚生成的权重遮罩，一层层累积到主画布上。
acc_roi += warped_roi * score_roi[:, :, None]
wsum_roi += score_roi
coverage_roi += valid_roi在叠图的同时，还需要考虑图像的色彩均衡。由于视频每一帧的曝光可能存在微小差异，直接拼合很容易产生一块亮一块暗的“补丁感”。为此，我们瞬间提取出两张图的重叠区域，计算出底图和新图的亮度均值比，然后将这个增益系数乘到新图片上。这样一来，新加入的图像在色彩和曝光上就与之前的相同了。
overlap = (wsum_roi > 1e-6) & (valid_roi > 0.5) & (score_roi > 1e-4)
if np.any(overlap):
curr_overlap = acc_roi[overlap] / wsum_roi[overlap, None]
ref_mean = curr_overlap.mean(axis=0)
src_mean = warped_roi[overlap].mean(axis=0)
gain = np.clip(ref_mean / np.maximum(src_mean, 1e-6), 0.88, 1.12)
warped_roi *= gain[None, None, :]所有的图层铺垫完毕后，我们用累加的像素值除以总权重，得出每一个像素最终的色彩。最后做有效区域裁边，去掉黑边，就得到了最后的成果全景图。
pano = (acc / np.maximum(wsum[:, :, None], 1e-6)).clip(0, 255).astype(np.uint8)
pano = crop_valid_area(pano, coverage)
性能优化
在跑通了全景拼接的完整流程后，我们面临着一个非常现实的工程挑战：慢。高清视频的单应性矩阵计算和透视变换会耗费大量的时间，而接下来我们需要通过优化架构设计加快程序运行速度。
多线程并发
在整个流程中，最吃 CPU 算力的环节有两个：一个是计算每一张图片的 SIFT/ORB 特征，另一个是将图片投射到大画布上的 Warp 透视变形。
因此我们引入 Python 的 ThreadPoolExecutor，将每一帧的预处理任务打包丢进线程池，让多个线程同时工作。各个线程完成任务的时间有先有后，于是我们利用字典记录下任务对应的帧索引 idx，在 as_completed 获取到结果后，再填回对应位置。
# 特征提取的并发
with ThreadPoolExecutor(max_workers=feat_workers) as executor:
futures = {executor.submit(compute_feature_pack, img, use_sift): i for i, img in enumerate(images)}
for future in as_completed(futures):
idx = futures[future]
features[idx] = future.result()# Warp 形变的并发
with ThreadPoolExecutor(max_workers=workers) as executor:
futures = {executor.submit(prepare_warp_pack, idx): idx for idx in batch_indices}
for future in as_completed(futures):
idx, bbox, warped_roi, score_roi, valid_roi = future.result()
batch_results[idx] = (bbox, warped_roi, score_roi, valid_roi)向量化与 ROI 局部运算
在传统的融合实现中，很容易犯一个极其消耗资源的错误：每一次将新图片融入大画布时，都在整张巨大的全景画布上进行计算。想象一下，一张全景画布可能是 8000x4000 的超高分辨率，而我们当前要贴上去的这一帧其实只占了其中很小的一块。如果每次都遍历整张大画布去算增益、算累加，绝大多数的算力都浪费在了黑边上。
针对这个问题，我们选择进行局部运算，只在有效区域（ROI, Region of Interest）内动刀。
具体来说，我们先利用 np.argwhere 找出变形后图像中真正有像素的边界，将这个子块单独切片出来。
# 锁定有效像素的边界
nz = np.argwhere(valid_mask > 0.5)
y0, x0 = np.min(nz, axis=0)
y1, x1 = np.max(nz, axis=0) + 1
# 仅切片提取有效区域 (ROI)
warped_roi = warped[y0:y1, x0:x1].astype(np.float32)
score_roi = score[y0:y1, x0:x1]
valid_roi = valid_mask[y0:y1, x0:x1]拿到切片后，我们在融合阶段也同样只对总画布 acc 和总权重 wsum 的对应局部区域进行操作。运算时配合 NumPy 原生的矩阵乘法，避免任何低效的 Python for 循环。
# 在大画布上切出对应的操作区
acc_roi = acc[y0:y1, x0:x1]
wsum_roi = wsum[y0:y1, x0:x1]
coverage_roi = coverage[y0:y1, x0:x1]
# 纯矩阵累加
acc_roi += warped_roi * score_roi[:, :, None]注
在使用多线程加速时，有一个关键约束：融合顺序必须严格保持不变。我们在计算色彩增益和像素累加时，当前帧的结果依赖于前面已经画好的底图状态。如果这部分也做并发，会导致严重的数据踩踏——即多个线程同时试图修改主画布上同一个像素的数值，导致部分帧的画面被相互覆盖或丢失，最终拼出带有随机色块和撕裂的废图。
所以，我们将并行优化仅仅限制在特征提取和 Warp 变形这些相互独立、可交换顺序的预处理步骤上。而当程序真正执行到更新 acc/wsum/coverage 这些全局画布状态时，依然老老实实地按照视频帧的先后顺序串行执行。保证结果与原逻辑一致。
完整 Python 代码
# Made by Wanakachi
from __future__ import annotations
import argparse
import math
import os
import subprocess
import time
from concurrent.futures import ThreadPoolExecutor, as_completed
from dataclasses import dataclass
from fractions import Fraction
from pathlib import Path
import cv2
import numpy as np
from tqdm.auto import tqdm
@dataclass
class FrameItem:
image: np.ndarray
frame_index: int
timestamp: float
def parse_time_to_seconds(text: str) -> float:
text = text.strip()
if ":" not in text:
return float(text)
hh, mm, ss = text.split(":")
return int(hh) * 3600 + int(mm) * 60 + float(ss)
def seconds_to_hhmmss(seconds: float) -> str:
hh = int(seconds // 3600)
mm = int((seconds % 3600) // 60)
ss = seconds - hh * 3600 - mm * 60
return f"{hh:02d}:{mm:02d}:{ss:09.6f}"
def probe_video_fps(video_path: str) -> float:
cmd = [
"ffprobe",
"-v",
"error",
"-select_streams",
"v:0",
"-show_entries",
"stream=avg_frame_rate",
"-of",
"default=noprint_wrappers=1:nokey=1",
video_path,
]
out = subprocess.check_output(cmd, text=True).strip()
if "/" in out:
return float(Fraction(out))
return float(out)
def snap_to_frame_time(time_sec: float, fps: float) -> tuple[int, float]:
idx = int(round(time_sec * fps))
return idx, idx / fps
def resize_keep_ratio(image: np.ndarray, target_width: int) -> np.ndarray:
if image.shape[1] <= target_width:
return image
scale = target_width / float(image.shape[1])
target_height = max(1, int(round(image.shape[0] * scale)))
return cv2.resize(image, (target_width, target_height), interpolation=cv2.INTER_AREA)
def blur_score(gray: np.ndarray) -> float:
return float(cv2.Laplacian(gray, cv2.CV_64F).var())
def estimate_motion(prev_gray: np.ndarray, curr_gray: np.ndarray) -> tuple[float, float]:
shift, response = cv2.phaseCorrelate(
prev_gray.astype(np.float32), curr_gray.astype(np.float32)
)
dx, dy = shift
return math.hypot(dx, dy), float(response)
def extract_keyframes(
video_path: str,
start_frame: int,
end_frame: int,
video_fps: float,
sample_fps: float,
min_blur: float,
min_motion_px: float,
force_keep_seconds: float,
preview_width: int,
max_keyframes: int,
) -> list[FrameItem]:
total_decode_frames = max(1, end_frame - start_frame + 1)
def sample_candidates(step: int) -> list[FrameItem]:
cap = cv2.VideoCapture(video_path)
if not cap.isOpened():
raise RuntimeError(f"Cannot open video: {video_path}")
cap.set(cv2.CAP_PROP_POS_FRAMES, start_frame)
pbar = tqdm(
total=total_decode_frames,
desc=f"decode(step={step})",
unit="f",
dynamic_ncols=True,
leave=False,
)
sampled: list[FrameItem] = []
frame_idx = start_frame
next_pick = start_frame
while frame_idx <= end_frame:
ok, frame = cap.read()
if not ok:
break
if frame_idx >= next_pick:
sampled.append(
FrameItem(
image=frame.copy(),
frame_index=frame_idx,
timestamp=frame_idx / video_fps,
)
)
next_pick += step
frame_idx += 1
pbar.update(1)
pbar.close()
cap.release()
return sampled
def filter_candidates(
candidates: list[FrameItem],
blur_thr: float,
motion_thr: float,
keep_gap_sec: float,
) -> list[FrameItem]:
if len(candidates) <= 2:
return candidates
pbar = tqdm(
total=max(1, len(candidates) - 1),
desc="keyframe-filter",
unit="f",
dynamic_ncols=True,
leave=False,
)
kept: list[FrameItem] = [candidates[0]]
last_kept_preview = cv2.cvtColor(
resize_keep_ratio(candidates[0].image, preview_width), cv2.COLOR_BGR2GRAY
)
last_kept_ts = candidates[0].timestamp
last_idx = len(candidates) - 1
for i, item in enumerate(candidates[1:], start=1):
preview = resize_keep_ratio(item.image, preview_width)
gray = cv2.cvtColor(preview, cv2.COLOR_BGR2GRAY)
# Always retain the final sampled frame if we still have too few keyframes.
if i == last_idx and len(kept) < 2:
kept.append(item)
last_kept_preview = gray
last_kept_ts = item.timestamp
pbar.update(1)
continue
if blur_score(gray) < blur_thr:
pbar.update(1)
continue
motion_px, response = estimate_motion(last_kept_preview, gray)
elapsed = item.timestamp - last_kept_ts
if motion_px >= motion_thr or (
elapsed >= keep_gap_sec and response < 0.20
):
kept.append(item)
last_kept_preview = gray
last_kept_ts = item.timestamp
pbar.update(1)
pbar.close()
if len(kept) < 2 and len(candidates) >= 2:
kept = [candidates[0], candidates[-1]]
return kept
def limit_keyframes(items: list[FrameItem], limit: int) -> list[FrameItem]:
if len(items) <= limit:
return items
picks = np.linspace(0, len(items) - 1, limit).astype(int)
return [items[i] for i in picks]
cap = cv2.VideoCapture(video_path)
if not cap.isOpened():
raise RuntimeError(f"Cannot open video: {video_path}")
step = max(1, int(round(video_fps / sample_fps)))
cap.release()
candidates = sample_candidates(step=step)
# Short clips or very low sample-fps may produce too few sampled frames.
# Automatically fallback to frame-by-frame sampling before giving up.
if len(candidates) < 2:
candidates = sample_candidates(step=1)
if len(candidates) < 2:
raise RuntimeError("Not enough frames in selected segment after decoding.")
keyframes = filter_candidates(
candidates=candidates,
blur_thr=min_blur,
motion_thr=min_motion_px,
keep_gap_sec=force_keep_seconds,
)
if len(keyframes) < 2:
keyframes = filter_candidates(
candidates=candidates,
blur_thr=max(0.0, min_blur * 0.45),
motion_thr=max(0.6, min_motion_px * 0.45),
keep_gap_sec=max(0.15, force_keep_seconds * 0.5),
)
if len(keyframes) >= 2:
print("[warn] Keyframe filter auto-relaxed for short/low-motion clip.")
if len(keyframes) < 2:
# Last fallback: keep all sampled frames to avoid false failure on short shots.
keyframes = candidates
print("[warn] Using all sampled frames because strict keyframe filtering was too aggressive.")
keyframes = limit_keyframes(keyframes, max_keyframes)
if len(keyframes) < 2:
raise RuntimeError(
"Not enough keyframes even after fallback. Try a slightly longer segment."
)
return keyframes
def feature_config() -> tuple[bool, int, float, int, int]:
use_sift = hasattr(cv2, "SIFT_create")
if use_sift:
return True, cv2.NORM_L2, 0.72, 40, 30
return False, cv2.NORM_HAMMING, 0.75, 30, 25
def compute_feature_pack(
bgr: np.ndarray,
use_sift: bool,
) -> tuple[np.ndarray, np.ndarray | None]:
gray = cv2.cvtColor(bgr, cv2.COLOR_BGR2GRAY)
if use_sift:
detector = cv2.SIFT_create(nfeatures=4000)
else:
detector = cv2.ORB_create(nfeatures=5000)
kp, des = detector.detectAndCompute(gray, None)
if not kp:
return np.empty((0, 2), dtype=np.float32), None
pts = np.float32([k.pt for k in kp])
return pts, des
def estimate_homography_from_packs(
prev_pack: tuple[np.ndarray, np.ndarray | None],
curr_pack: tuple[np.ndarray, np.ndarray | None],
norm: int,
ratio: float,
min_kp: int,
min_good: int,
) -> np.ndarray | None:
prev_pts, des1 = prev_pack
curr_pts, des2 = curr_pack
if des1 is None or des2 is None or len(prev_pts) < min_kp or len(curr_pts) < min_kp:
return None
matcher = cv2.BFMatcher(norm)
knn = matcher.knnMatch(des1, des2, k=2)
good = []
for pair in knn:
if len(pair) < 2:
continue
m, n = pair
if m.distance < ratio * n.distance:
good.append(m)
if len(good) < min_good:
return None
src = np.float32([curr_pts[m.trainIdx] for m in good]).reshape(-1, 1, 2)
dst = np.float32([prev_pts[m.queryIdx] for m in good]).reshape(-1, 1, 2)
h, inliers = cv2.findHomography(src, dst, cv2.RANSAC, 3.0)
if h is None or inliers is None:
return None
inlier_ratio = float(inliers.sum()) / max(1, len(inliers))
if inlier_ratio < 0.22:
return None
return h
def build_soft_weight(shape: tuple[int, int], feather_radius: int) -> np.ndarray:
h, w = shape
src_mask = np.full((h, w), 255, dtype=np.uint8)
k = max(3, feather_radius)
if k % 2 == 0:
k += 1
kernel = cv2.getStructuringElement(cv2.MORPH_ELLIPSE, (k, k))
inner = cv2.erode(src_mask, kernel)
dist = cv2.distanceTransform(inner, cv2.DIST_L2, 3)
if float(dist.max()) <= 1e-6:
return np.ones((h, w), dtype=np.float32)
dist = dist / float(dist.max())
return np.clip(dist, 0.05, 1.0).astype(np.float32)
def crop_valid_area(image: np.ndarray, weight: np.ndarray) -> np.ndarray:
valid = (weight > 0.01).astype(np.uint8) * 255
points = cv2.findNonZero(valid)
if points is None:
return image
x, y, w, h = cv2.boundingRect(points)
return image[y : y + h, x : x + w]
def stitch_panorama(
keyframes: list[FrameItem],
stitch_width: int,
max_output_megapixels: float,
feather_radius: int,
) -> tuple[np.ndarray, int]:
stitch_start = time.perf_counter()
images = [resize_keep_ratio(item.image, stitch_width) for item in keyframes]
use_sift, norm, ratio, min_kp, min_good = feature_config()
feat_start = time.perf_counter()
features: list[tuple[np.ndarray, np.ndarray | None] | None] = [None] * len(images)
feat_workers = min(max(1, os.cpu_count() or 1), len(images), 8)
with tqdm(total=len(images), desc="feature-prep", unit="f", dynamic_ncols=True, leave=False) as feat_pbar:
with ThreadPoolExecutor(max_workers=feat_workers) as executor:
futures = {executor.submit(compute_feature_pack, img, use_sift): i for i, img in enumerate(images)}
for future in as_completed(futures):
idx = futures[future]
features[idx] = future.result()
feat_pbar.update(1)
print(f"[time] feature precompute ({feat_workers} threads): {time.perf_counter() - feat_start:.2f}s")
chain: list[np.ndarray] = [np.eye(3, dtype=np.float64)] # i -> 0
accepted = [images[0]]
accepted_indices = [0]
h_start = time.perf_counter()
with tqdm(
total=max(1, len(images) - 1),
desc="homography",
unit="f",
dynamic_ncols=True,
leave=False,
) as h_pbar:
for i in range(1, len(images)):
prev_idx = accepted_indices[-1]
prev_pack = features[prev_idx]
curr_pack = features[i]
if prev_pack is None or curr_pack is None:
h_pbar.update(1)
continue
h_curr_to_prev = estimate_homography_from_packs(
prev_pack, curr_pack, norm, ratio, min_kp, min_good
)
if h_curr_to_prev is None:
h_pbar.update(1)
continue
h_curr_to_0 = chain[-1] @ h_curr_to_prev
chain.append(h_curr_to_0)
accepted.append(images[i])
accepted_indices.append(i)
h_pbar.update(1)
print(f"[time] homography chain: {time.perf_counter() - h_start:.2f}s")
if len(accepted) < 2:
raise RuntimeError("Cannot stitch: insufficient reliable frame matches.")
# Use middle frame as reference to reduce long-chain distortion.
ref_idx = len(accepted) // 2
ref_inv = np.linalg.inv(chain[ref_idx])
transforms = [ref_inv @ h for h in chain] # i -> ref
corners_all = []
for img, h in zip(accepted, transforms):
hh, ww = img.shape[:2]
corners = np.array([[0, 0], [ww, 0], [ww, hh], [0, hh]], dtype=np.float32).reshape(
-1, 1, 2
)
corners_all.append(cv2.perspectiveTransform(corners, h))
all_pts = np.concatenate(corners_all, axis=0).reshape(-1, 2)
min_x, min_y = np.min(all_pts, axis=0)
max_x, max_y = np.max(all_pts, axis=0)
out_w = max(1, int(math.ceil(float(max_x - min_x))))
out_h = max(1, int(math.ceil(float(max_y - min_y))))
max_pixels = max_output_megapixels * 1_000_000.0
scale = 1.0
if out_w * out_h > max_pixels:
scale = math.sqrt(max_pixels / float(out_w * out_h))
out_w = max(1, int(round(out_w * scale)))
out_h = max(1, int(round(out_h * scale)))
shift = np.array(
[[1.0, 0.0, -float(min_x)], [0.0, 1.0, -float(min_y)], [0.0, 0.0, 1.0]],
dtype=np.float64,
)
resize_h = np.array(
[[scale, 0.0, 0.0], [0.0, scale, 0.0], [0.0, 0.0, 1.0]], dtype=np.float64
)
# First-version style blending: weighted averaging across frames.
# Improve seam quality by stronger edge falloff + mild overlap color balancing.
acc = np.zeros((out_h, out_w, 3), dtype=np.float32)
wsum = np.zeros((out_h, out_w), dtype=np.float32)
coverage = np.zeros((out_h, out_w), dtype=np.float32)
sharpness_values = []
for img in accepted:
gray = cv2.cvtColor(img, cv2.COLOR_BGR2GRAY)
sharpness_values.append(blur_score(gray))
sharpness_values = np.array(sharpness_values, dtype=np.float32)
if float(sharpness_values.max()) > float(sharpness_values.min()):
sharpness_norm = 0.85 + 0.30 * (
(sharpness_values - sharpness_values.min())
/ (sharpness_values.max() - sharpness_values.min())
)
else:
sharpness_norm = np.ones_like(sharpness_values, dtype=np.float32)
weight_cache: dict[tuple[int, int], np.ndarray] = {}
valid_cache: dict[tuple[int, int], np.ndarray] = {}
for img in accepted:
shape_key = (img.shape[0], img.shape[1])
if shape_key not in weight_cache:
weight_cache[shape_key] = build_soft_weight(shape_key, feather_radius)
valid_cache[shape_key] = np.ones(shape_key, dtype=np.float32)
def prepare_warp_pack(
idx: int,
) -> tuple[int, tuple[int, int, int, int] | None, np.ndarray | None, np.ndarray | None, np.ndarray | None]:
img = accepted[idx]
h = transforms[idx]
h_canvas = resize_h @ shift @ h
warped = cv2.warpPerspective(
img, h_canvas, (out_w, out_h), flags=cv2.INTER_LINEAR, borderMode=cv2.BORDER_CONSTANT
)
shape_key = (img.shape[0], img.shape[1])
src_weight = weight_cache[shape_key]
src_valid = valid_cache[shape_key]
w = cv2.warpPerspective(
src_weight,
h_canvas,
(out_w, out_h),
flags=cv2.INTER_LINEAR,
borderMode=cv2.BORDER_CONSTANT,
)
valid_soft = cv2.warpPerspective(
src_valid,
h_canvas,
(out_w, out_h),
flags=cv2.INTER_LINEAR,
borderMode=cv2.BORDER_CONSTANT,
)
valid_mask = (valid_soft > 0.6).astype(np.float32)
valid_u8 = (valid_mask * 255).astype(np.uint8)
valid_u8 = cv2.erode(valid_u8, np.ones((3, 3), np.uint8), iterations=1)
valid_mask = (valid_u8 > 0).astype(np.float32)
score = (w * valid_mask * sharpness_norm[idx]).astype(np.float32)
nz = np.argwhere(valid_mask > 0.5)
if nz.size == 0:
return idx, None, None, None, None
y0, x0 = np.min(nz, axis=0)
y1, x1 = np.max(nz, axis=0) + 1
warped_roi = warped[y0:y1, x0:x1].astype(np.float32)
score_roi = score[y0:y1, x0:x1]
valid_roi = valid_mask[y0:y1, x0:x1]
return idx, (int(y0), int(y1), int(x0), int(x1)), warped_roi, score_roi, valid_roi
prep_start = time.perf_counter()
workers = min(max(1, os.cpu_count() or 1), len(accepted), 8)
batch_size = max(8, workers * 2)
blend_start = time.perf_counter()
prep_elapsed = 0.0
blend_elapsed = 0.0
with tqdm(total=len(accepted), desc="warp-prep", unit="f", dynamic_ncols=True, leave=False) as prep_pbar:
with tqdm(total=len(accepted), desc="blend", unit="f", dynamic_ncols=True, leave=False) as blend_pbar:
with ThreadPoolExecutor(max_workers=workers) as executor:
for batch_start in range(0, len(accepted), batch_size):
batch_indices = list(range(batch_start, min(batch_start + batch_size, len(accepted))))
t0 = time.perf_counter()
futures = {
executor.submit(prepare_warp_pack, idx): idx for idx in batch_indices
}
batch_results: dict[
int,
tuple[
tuple[int, int, int, int] | None,
np.ndarray | None,
np.ndarray | None,
np.ndarray | None,
],
] = {}
for future in as_completed(futures):
idx, bbox, warped_roi, score_roi, valid_roi = future.result()
batch_results[idx] = (bbox, warped_roi, score_roi, valid_roi)
prep_pbar.update(1)
prep_elapsed += time.perf_counter() - t0
t1 = time.perf_counter()
for idx in batch_indices:
packed = batch_results.get(idx)
if packed is None:
blend_pbar.update(1)
continue
bbox, warped_roi, score_roi, valid_roi = packed
if (
bbox is None
or warped_roi is None
or score_roi is None
or valid_roi is None
):
blend_pbar.update(1)
continue
y0, y1, x0, x1 = bbox
acc_roi = acc[y0:y1, x0:x1]
wsum_roi = wsum[y0:y1, x0:x1]
coverage_roi = coverage[y0:y1, x0:x1]
# Mild per-frame color gain alignment in overlap to reduce "block" perception.
overlap = (wsum_roi > 1e-6) & (valid_roi > 0.5) & (score_roi > 1e-4)
if np.any(overlap):
curr_overlap = acc_roi[overlap] / wsum_roi[overlap, None]
ref_mean = curr_overlap.mean(axis=0)
src_mean = warped_roi[overlap].mean(axis=0)
gain = ref_mean / np.maximum(src_mean, 1e-6)
gain = np.clip(gain, 0.88, 1.12)
warped_roi *= gain[None, None, :]
np.clip(warped_roi, 0.0, 255.0, out=warped_roi)
acc_roi += warped_roi * score_roi[:, :, None]
wsum_roi += score_roi
coverage_roi += valid_roi
blend_pbar.update(1)
blend_elapsed += time.perf_counter() - t1
print(f"[time] warp precompute ({workers} threads): {prep_elapsed:.2f}s")
print(f"[time] blend accumulate: {blend_elapsed:.2f}s")
pano = (acc / np.maximum(wsum[:, :, None], 1e-6)).clip(0, 255).astype(np.uint8)
pano = crop_valid_area(pano, coverage)
print(f"[time] stitch total: {time.perf_counter() - stitch_start:.2f}s")
return pano, len(accepted)
def main() -> None:
total_start = time.perf_counter()
parser = argparse.ArgumentParser(
description="Extract keyframes from a video segment and stitch a large object panorama."
)
parser.add_argument("input_video", help="Input video path.")
parser.add_argument("output_image", help="Output panorama image path.")
parser.add_argument("--start", required=True, help="Start time, e.g. 00:47:24.216")
parser.add_argument("--end", required=True, help="End time, e.g. 00:47:34.310")
parser.add_argument("--sample-fps", type=float, default=12.0, help="Sampling fps. Default: 12")
args = parser.parse_args()
# Quality-oriented defaults (keep these fixed unless you have a special scene):
# - PREVIEW_WIDTH/STITCH_WIDTH: full-HD level feature matching and output sharpness.
# - MIN_BLUR/MIN_MOTION_PX: avoid blurry/duplicate frames while keeping camera motion continuity.
# - FORCE_KEEP_SECONDS: force sparse keep in low-texture regions to avoid missing areas.
# - FEATHER_RADIUS: larger value softens seams and reduces block-like stitching artifacts.
# - MAX_OUTPUT_MP: keep high-resolution panorama, but prevent uncontrolled memory growth.
PREVIEW_WIDTH = 1920
STITCH_WIDTH = 1920
MIN_BLUR = 18.0
MIN_MOTION_PX = 4.0
FORCE_KEEP_SECONDS = 0.5
MAX_KEYFRAMES = 260
FEATHER_RADIUS = 71
MAX_OUTPUT_MP = 120.0
if not os.path.isfile(args.input_video):
raise FileNotFoundError(f"Input video does not exist: {args.input_video}")
if args.sample_fps <= 0:
raise ValueError("--sample-fps must be > 0")
fps = probe_video_fps(args.input_video)
start_raw = parse_time_to_seconds(args.start)
end_raw = parse_time_to_seconds(args.end)
if end_raw <= start_raw:
raise ValueError("--end must be later than --start")
start_idx, start_precise = snap_to_frame_time(start_raw, fps)
end_idx, end_precise = snap_to_frame_time(end_raw, fps)
if end_idx <= start_idx:
end_idx = start_idx + 1
end_precise = end_idx / fps
print(f"[info] fps={fps:.6f}")
print(
f"[info] precise segment: {seconds_to_hhmmss(start_precise)} -> "
f"{seconds_to_hhmmss(end_precise)} (frame {start_idx} -> {end_idx})"
)
extract_start = time.perf_counter()
keyframes = extract_keyframes(
video_path=args.input_video,
start_frame=start_idx,
end_frame=end_idx,
video_fps=fps,
sample_fps=args.sample_fps,
min_blur=MIN_BLUR,
min_motion_px=MIN_MOTION_PX,
force_keep_seconds=FORCE_KEEP_SECONDS,
preview_width=PREVIEW_WIDTH,
max_keyframes=MAX_KEYFRAMES,
)
print(f"[time] keyframe extraction: {time.perf_counter() - extract_start:.2f}s")
print(f"[1/2] keyframes selected: {len(keyframes)}")
stitch_start = time.perf_counter()
pano, used = stitch_panorama(
keyframes=keyframes,
stitch_width=STITCH_WIDTH,
max_output_megapixels=MAX_OUTPUT_MP,
feather_radius=FEATHER_RADIUS,
)
print(f"[time] stitch pipeline: {time.perf_counter() - stitch_start:.2f}s")
print(f"[2/2] stitched frames: {used}/{len(keyframes)}")
write_start = time.perf_counter()
out_path = Path(args.output_image).resolve()
out_path.parent.mkdir(parents=True, exist_ok=True)
if not cv2.imwrite(str(out_path), pano):
raise RuntimeError(f"Failed to write output image: {out_path}")
print(f"[time] write image: {time.perf_counter() - write_start:.2f}s")
print(f"[time] total runtime: {time.perf_counter() - total_start:.2f}s")
print(f"[done] panorama saved: {out_path}")
if __name__ == "__main__":
main()
